Thermal Imaging
Three thermal platforms sharing one detector philosophy — 384×288 / 640×480 microbolometers with 8–12 μm optics — packaged for the clip-on, the firefighter’s hand and the long-range binocular (manufacturer specifications)†.
DT-TW21 — Thermal Clip-On (92 g)
Hand-held, head-mounted or clipped in front of PVS31/PVS14/NVG18/DTG18-class night vision — adds heat detection to your existing kit at 92 g. IP67†. Full specifications →
Firefighter Thermal Cameras
Hand-held and helmet-mounted thermal cameras built for smoke penetration: 384×288 or 320×240 detectors, IP67/68 sealing, −25~+85 °C operation† — find missing persons and hot spots through heavy smoke.
ZXD05 Thermal Binoculars
Dual-sensor binoculars with 1440×1080 fusion, 640×512 / 12 μm thermal channel, 50 Hz, DDE image enhancement, laser rangefinder to 1,000 m (±0.5 m)†; IP67, MIL-STD-810H, −40~+55 °C.
Applications
Fireground search & hot-spot location · Outdoor thermal spotting · Law-enforcement night search · Industrial inspection · Security patrol
Product Images
FAQ
Clip-on or dedicated camera?
Clip-on (DT-TW21) upgrades night vision you already own; dedicated firefighter cameras are optimized for smoke and gloved operation. Many teams run both.
What does the binocular rangefinder add?
1,000 m laser ranging (±0.5 m) — distance to the heat source, not just its bearing (manufacturer specification).
